BMW X5: TECHNICAL DATA.
| Weight | |
|---|---|
|
Unladen weight EU in kg
|
2,510
|
|
Max. permissible weight in kg
|
3150
|
|
Permitted load in kg
|
715
|
|
Permitted axle load front/rear
in kg
|
1,390/1,810
|
|
Luggage capacity min. (seats up
or roof down) in l
|
500
|
|
Luggage capacity max. (seats
down or roof up) in l
|
1,720
|
|
Trailer load (unbraked) in kg
|
750
|
|
Trailer load 8% (braked) in kg
|
-
|
|
Trailer load 12% (braked) in
kg
|
2,700
|
| Engine | |
|---|---|
|
Cylinders/valves
|
6/4
|
|
Capacity in ccm
|
2.998
|
|
Stroke/bore in mm
|
94.6/82.0
|
|
Engine power in kW (hp) at
1/min
|
210 (286)/5,000-6,000
|
|
Engine torque (Nm) at 1/min
|
450/1,500-3,500
|
|
Compression ratio : 1
|
11.0
|
| Performance | |
|---|---|
|
Top speed in km/h
|
235
|
|
Acceleration 0–100 km/h in s
|
5.6
|
|
Electrical engine top speed in
km/h
|
135
|
| Fuel consumption | |
|---|---|
|
Urban in l/100 km
|
-
|
|
Extra-urban in l/100 km
|
-
|
|
Combined in l/100 km
|
2.5
|
|
CO2 combined emissions in g/km
|
56
|
|
Electricity consumption,
combined in kWh/100km
|
25.7
|
|
Tank capacity, approx. in l
|
69
|
| Wheels | |
|---|---|
|
Tyre dimensions front
|
265/50 R19 110W XL
|
|
Tyre dimensions rear
|
265/50 R19 110W XL
|
|
Wheel dimensions and material
front
|
9 J x 19 inches, light-alloy
|
|
Wheel dimensions and material
rear
|
9 J x 19 inches, light-alloy
|
| Range and charging | |
|---|---|
|
Electric range in km
|
77
|
|
Growth capacity of lithium-ion
battery in kWh
|
24.0
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
|
5.0
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
6.8
|
| Electric engine | |
|---|---|
|
Electric engine power kW (PS) at 1/min
|
83 (113)/3,170
|
|
Electric Engine torque (Nm) at
1/min
|
265/0-3,170
|
| Combined system power | |
|---|---|
|
Combined power kW (hp)
|
290 (394)
|
|
Combined torque Nm
|
600
|
| Weight | |
|---|---|
|
Unladen weight EU in kg
|
1,615
|
|
Max. permissible weight in kg
|
2,220
|
|
Permitted load in kg
|
680
|
|
Permitted axle load front/rear
in kg
|
1,065/1,255
|
|
Luggage capacity min. (seats up
or roof down) in l
|
530
|
|
Luggage capacity max. (seats
down or roof up) in l
|
-
|
|
Trailer load (unbraked) in kg
|
750
|
|
Trailer load 8% (braked) in kg
|
-
|
|
Trailer load 12% (braked) in
kg
|
2,000
|
| Engine | |
|---|---|
|
Cylinders/valves
|
4/4
|
|
Capacity in ccm
|
1,998
|
|
Stroke/bore in mm
|
94.6/82.0
|
|
Engine power in kW (hp) at
1/min
|
183 (249)/5,200-6,500
|
|
Engine torque (Nm) at 1/min
|
350/1,450-4,800
|
|
Compression ratio : 1
|
10.2
|
| Performance | |
|---|---|
|
Top speed in km/h
|
250
|
|
Acceleration 0–100 km/h in s
|
6.1
|
|
Electrical engine top speed in
km/h
|
-
|
| Fuel consumption | |
|---|---|
|
Urban in l/100 km
|
8.0
|
|
Extra-urban in l/100 km
|
5.7
|
|
Combined in l/100 km
|
6.5
|
|
CO2 combined emissions in g/km
|
149
|
|
Electricity consumption,
combined in kWh/100km
|
-
|
|
Tank capacity, approx. in l
|
68
|
| Wheels | |
|---|---|
|
Tyre dimensions front
|
245/35 R20 95 Y XL
|
|
Tyre dimensions rear
|
275/30 R20 97 Y XL
|
|
Wheel dimensions and material
front
|
8 J x 20 inches, light-alloy
|
|
Wheel dimensions and material
rear
|
9 J x 20 inches, ligth-alloy
|
| Range and charging | |
|---|---|
|
Electric range in km
|
-
|
|
Growth capacity of lithium-ion
battery in kWh
|
-
|
|
Charging time 3,7 kW/16 A, BMW i
Wallbox (100 %) h
|
-
|
| Electric engine | |
|---|---|
|
Electric engine power kW (hp) at
1/min
|
-
|
|
Electric Engine torque (Nm) at
1/min
|
-
|
| Combined system power | |
|---|---|
|
Combined power kW (hp)
|
-
|
|
Combined torque Nm
|
-
|
Fuel consumption and CO2 emissions.
-
BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 2.5
CO2 emissions in g/km (combined): 56
Electricity consumption combined in kWh/100 km: 25.7
The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.
The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.
For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
